POLYURETHANE EDGE SEALING ROCK WOOL EXTERIOR WALL PANEL

Aqua Route Polyurethane Edge-Sealing Glass Wool Sandwich Panel combines the Class A non-combustible fire performance of glass wool core with the superior waterproofing, airtightness, and thermal bridge blocking of polyurethane edge sealing, delivering exceptional fire safety and energy efficiency. The glass wool core ensures outstanding fire resistance, sound insulation, and thermal stability, while polyurethane edges enhance overall insulation, moisture resistance, and durability, preventing core absorption and maintaining long-term performance.

Total Fire integrity & Zero Leakage: PU Edge-Sealed Rock Wool Panels for Advanced industrial Enclosures

The Polyurethane Edge-Sealing Rock Wool Exterior Wall Panel combines uncompromising fire resistance with the precision weather-proofing of polyurethane sealing technology. This advanced hybrid solution is designed for mission-critical industrial roofing and facades where fire safety, structural rigidity, and total moisture prevention must coexist.

Core Competitive Advantages

Advanced PU Edge Injection: Precision-milled PU edges block 100% of moisture penetration, preventing common rock wool degradation and maintaining core structural integrity for the entire building lifecycle.
Class A Fire Barrier: Features a mineral rock wool core with a melting point above 1000°C, delivering essential fire protection for hazardous material sites and oil & gas facilities.
Hidden Fastening Aesthetic: Utilizes a hidden-fix joint system that ensures a seamless, fastener-free appearance while maximizing wind-load resistance and airtightness.
High-Density Structural Shield: Core density (≥ 100-120 kg/m³) provides superior impact resistance and mechanical stability compared to standard sandwich panels.

Key Technical Specifications

Technical Parameter	Engineering Specification
Joint / Connection System	Hidden Screw Tongue & Groove System
Steel Skin Thickness Range	0.4 mm – 0.8 mm
Core Material & Density	PU Edge-Sealed Rock Wool (Density ≥ 100-120 kg/m³)
Exterior Metal Coating	PE / SMP / HDP / PVDF
Effective Width	1000 mm
Structural Benefit	Seamless architectural aesthetics with enhanced wind-load resistance

Upgrade your building envelope with industrial-grade fire barriers. Contact our engineering team for factory-direct quotes and layouts.

Technical Specs

Aqua Route — Factory Direct Technical Specification
Parameter	Specification
Surface Material	Steel / Aluminum
Surface Thickness	Steel 0.4–0.8 mm Aluminum 0.6–1.0 mm
Panel Thickness	50 mm · 75 mm · 100 mm · 120 mm · 150 mm
Effective Width	1,000 mm
Length	Customizable
Core Density	Rock Wool ≥ 100 kg/m³ Glass Wool ≥ 64 kg/m³
Thermal Conductivity	Rock Wool: 0.34–0.40 W/(m·K) Glass Wool: 0.32–0.44 W/(m·K) Specifically calculated based on density and thickness.
Fire Rating	Grade A
Surface Types	Wide Ripplet · Ripplet · Embossed

FAQ

`Q1: What are the main materials used in your metal enclosure systems?`

 Our metal enclosure systems use sandwich panels with cores of Rock Wool (Class A fire resistance) or PIR/PUR (superior thermal insulation), with galvanized or pre-painted steel facings. Standard effective width is 1000mm for mechanically produced panels. Panels are available for exterior wall and roof applications in industrial and commercial buildings.

`Q2: Can I customize the dimensions and colors of the panels?`

 Yes. We offer full OEM/ODM customization — specify lengths up to 12m, core thickness, and color from the RAL chart. Custom colors require a minimum of 2,000 m² per order.

`Q3: What fire safety certifications do your enclosure panels hold?`

 Our panels carry ISO 9001:2015, CE marking, and SGS third-party verification. We provide fire resistance ratings and thermal conductivity test reports on request.

`Q4: Do you provide installation support for large-scale enclosure projects?`

 We provide installation manuals and video tutorials. For major industrial projects, engineers can be dispatched for on-site technical guidance (client covers travel expenses)

`Q5: What is the standard lead time for a bulk order?`

 Production takes 15-20 working days. Sea freight adds 20-35 days depending on destination port. Rush production (10-12 days) is available for time-sensitive orders.

Additional information

Brand	Aqua Route
Product Type	Exterior Wall Panel
Insulation Core	Rock Wool
Edge Seal	Polyurethane
Fire Rating	Class A
